Quiosques Android · Zonerich
Quiosque c / Dispensador de Líquidos ZQ-SK20 - LCD 21.5" Não Touch / Android 4.4.2
Ref. POS177 · EAN 5600373303118
701,10 €
Preço com IVA incluído (23%)
Descrição
- Zonerich
- Automatic Waterless Sanitizer Dispenser
- ZQ-SK20
- The dispenser terminal integrates functions of advertising and waterless sanitizer spray dispensing to prevent from human direct contact so that virus wont spread human by human. The advertising function extend the advertise broadcasting to people who use waterless sanitizer spray. The terminal perfectly be applicable for public situations, such as toilets, shopping mall, cinemas, theatre etc.
- Features
- To support dual LVDS displays;
- To support 2K HD video playing;
- To support HDMI channel with 4K: 2K @60Hz video input, FHD displaying;
- To support horizontal/vertical soft two videos / graphics / texts;
- To support full display CVBS output (externally optional);
- To support Ethernet / WIFI / 3G/4G (optional) and WOE function;
- To support dual UART connection (one is TTL and the other is DEBUG);
- To support timing switch function;
- To support TF card extendable with max. to 128GB;
- To support mobile phone screen mirroring function.
- Specifications
- CPU: ARM Cortex A53 Dual Core, 64bit, 1.2GHz
- Chipset: H3/751 V310
- GPU: Mali-450 Quad-Core 3D GPU (supports OpenGL ES 2.0/1.1 & OpenVG 1.1)
- RAM: 1GB DDR as standard
- Display: 21.5 TFT-LCD, 1920×1080p, LVDS
- Video Input: 480i, 576i
- Video System: PAL / NTSC / SECAM
- Video Level: 1.0 VP-P ±5%
- HDMI: 480i, 480p, 576i, 576p, 720p, 1080i, 1080p, 4K2K
- UART: TTL
- USB: 2.0
- TF-Card: TF card (max 128GB)
- Audio Input: MPEG1/2 L2, H.264, VC-1, MPEG-4 up to 1080p
- Audio Output: Analog L/R, Digital Coaxial, SPDIF
- Audio Decode: Dolby Digital (AC3), Dolby TrueHD, DTS, DTS-HD, MPEG L1/L2, MP3, AAC, HE-AACV2, LPCM, APE, FLAC, OggVorbis, ARM-NB, ARM-WB, G.711(A/u), etc.
- Audio Output Level: 2 Vrms (L/R RCA output), 250mVrms (1.0Vp-p ±10%)
- Audio Output Power: 10W×2 (8ohm) THD+N =1% @10%×1KHz
- Power Supply: 5V/3A or 12V (20 panel)
- Power Consumption: Lower than 0.5W
- Ethernet: 802.11 b/g/n, built-in module optional, need ANT.
- Ethernet Network: 10/100M auto-identification and DHCP, USB driver.
- 3G/4G: Optional.
- Working Temp: -10°C ~ 55°C
- Storage Temp: -20°C ~ 60°C
